Mud Drilling

Solids Separation Equipment


FS300 Shale Shaker

  • Adjustable single deck with 3 panel screens

  • Loop isolators

  • 58.5 square feet of screen area

  • Basket powered by two 2.5HP, 3-phase 230/460V 60Hz explosion proof Vimarc Vibrator motors.

Features:

O'Drill/MCM FS400 Shaker

FS400 Shale Shaker

  • Adjustable single deck with 4 panel screens

  • Loop isolators

  • 58.5 square feet of screen area

  • Basket powered by two 2.5HP, 3-phase 230/460V 60Hz explosion proof Vimarc Vibrator motors.

Features:

Single Standard Shaker.jpg

Single Standard Shale Shaker

  • SSS orbital motion

  • Hard rubber shock mounts

  • 20 square feet of screen area

  • 4’ x 5’ hook strip screens

  • Powered by a 5HP 3-phase 230/460V 60Hz explosion proof belt-driven motor.

Features:

Dual Standard Shaker.jpg

Dual Standard Shale Shaker

  • DSS orbital motion

  • Hard rubber shock mounts

  • 40 square feet of screen area

  • 4’ x 5’ hook strip screens

  • Powered by a 3HP 3-phase 230/460V 60Hz explosion proof belt-driven motor.

Features:

Single Tandem Shaker.jpg

Single Tandem Shale Shaker

  • STS orbital motion

  • Hard rubber shock mounts

  • 40 square feet of screen area

  • 4’ x 5’ hook strip screens

  • Flow back pan beneath upper screen

  • Powered by a 5HP 3-phase 230/460V 60Hz explosion proof belt-driven motor.

Features:

Dual Tandem Shaker.png

Dual Tandem Shale Shaker

  • Two orbital motion tandem deck shakers mounted on a common base with common possum belly deck

  • Hard rubber shock mounts

  • 80 square feet of screen area

  • 4’ x 5’ hook strip screens

  • Flow back pan beneath upper screen

  • Powered by a 3HP 3-phase 230/460V 60Hz explosion proof belt-driven motor.

Features:

Junior Standard Shaker.jpg

Junior Standard Shale Shaker

  • SSS orbital motion

  • Hard rubber shock mounts

  • 9 square feet of screen area

  • 3’ x 3’ hook strip screens

  • Powered by a 2HP 3-phase 230/460V 60Hz explosion proof belt-driven motor.

Features:


Mud Cleaner

  • Features a FS300 linear-motion shale shaker with a variety of possible desilter/desander cone arrangements manifolded above the screen deck

  • Space saving model that can flow up to 1000/GPM.

    ​

Features:

Mud Agitator.png

Mud Agitator

  • Ultra-tough Cast Iron gear box (nominal ratio 30:1)

  • Precision-ground gear sets to eliminate backlash

  • Helical-bevel gear box achieves the highest efficiency available.

  • Available in 3HP to 30HP sizes.

Features:

Mud Hopper.jpg

Mud Hopper

  • Available in 4” and 6” sizes with butterfly valve, Venturi discharge nozzle, jet nozzle, tees, studs and a sack cutting table capacity up to 650/GPM.

Features:

Mud Gun.jpg

Low Pressure Mud Gun

  • Available in 2” and 3” sizes with a swivel joint, handle and jet nozzle at the bottom to stir tanks with lengths to meet your tank depth requirements.

Features:

Mud Bucket.jpg

Mud Bucket

  • Designed to prevent drilling fluid loss on the rig floor

  •  Reduce wash downs due to a slippery rig floor

  • 6’ x 11-3/4”

  • Made to fit drill pipe sizes from 2-3/8” to 5-1/2”

  • Now available in a 4’ model

Features:

Vertical Desander.jpg

Desander

  • Manifold constructed of 8” Sch 40 pipe mounted on an angle iron base

  • 10” cones with grooved end inlets and overflows

  • Desanding capacity from 500 to 1500/GPM.

Features:

Desilter

Desilter

  • Manifold constructed of 6” Sch 40 pipe mounted on an angle iron base

  • 4” or 5” cones with grooved end inlets and overflows

  • Desilting capacity from 400 to 1280/GPM.

Features:
